Автомобильный металлический автоматический выключатель 30А 12В для лодки на колесах

Auto Reset Circuit Breaker 30 AMP 14V-28V Fuse Dual Battery Car Caravan Boat

Description:

100% brand new and high quality

Meterial: metal

Voltage: 12V, 30A

For use in electric brake set ups, auto , caravans and more

One copper post and one plated terminal

Battery side connects to the copper side and the plated side connects to your accessories generally take the place of a fuse but with the advantage of resetting itself,Ideal in applications where what is being connected could have a short circuit or a momentary short.

Specification:

Stud Type Circuit Breaker

Battery chargers, trucks, buses, RVs, trolling motors, etc

SAE J553; SAE J1171; UL1500

Voltage 14-28Vdc

Rated Current 30A

Mounting Parallel (Lengthwise) Mounting Bracket

Reset Type T1, Auto Reset

Operating Temperature -40ºC (-40ºF) to 85ºC (185ºF)

Interrupt Capacity 2.5kA @ 12Vdc

Dimension 1.248 x 0.693 x 0.8 inch

Regulatory Sepcification SAE J553; SAE J1171; UL1500

Termination #10-32 thread

Body Metal Cabinet

Storage Temperature -40ºC (-40ºF) to 125ºC (260ºF)

Package Includes:

1 Piece Circuit Breaker

2 Pieces Screw Nuts
